Tower

3 metres

Chassis

Rubber tracks

drilling Diameter(mm)

130-254

Drilling Depth(m)

180

Length of One-Time Advance(m)

3.6

Travelling Speed(km/h)

2.5

Maximum Climbing Capability of Single Engine

30

Engine Brand

Yunei

Main Engine Power

42kw

Working Air Pressure(mpa)

1.45-2.5

Air Consumption(m v3/min)

17-31

Drill Pipe Diametermm

76/89

Drill Pipe Lengthm

1.5/2.0/3.0

Lifting Force(T)

12

Slewing Speed(rpm)

40-65

Slewing Torque(H.m)

3500-3800

Overall Dimensionsmm

3500*1700*2250

Total Machine Weight(T)

4.5
